Helix M ONE X

Small, efficient and uncompromisingly stable - the M ONE is a highly compact monoblock for subwoofer applications. Designed from latest Class D technology this tiny amp can easily control speakers with 1 Ohm impedance. Its current capability makes the M ONE a perfect partner for 2 x 2 Ohms subwoofers, where both voice coils are connected in parallel. In addition a comprehensive and stunningly practical feature set leaves nothing to be desired. Last but not least installation will be a no-brainer due to its super-compact dimensions. Power RMS ≤ 1% THD+NNormal operation (One amplifier)TwinPower Link (Two amplifiers): - @ 4 Ohms 1 x 400 Watts, TwinPower Link 1 x 1,400 Watts - @ 2 Ohms 1 x 700 Watts, TwinPower Link 1 x 2,060 Watts - @ 1 Ohm1 x 1,030 Watts - Amplifier technologyClass D - Inputs2 x RCA / Cinch - 2 x Highlevel speaker input - 1 x Remote In - 1 x Remote control input - Input sensitivityRCA / Cinch 0.5 - 6 Volts - Highlevel 1.1 - 13 Volts - Input impedance RCA / Cinch20 kOhms - Input impedance highlevel9 - 33 Ohms - Outputs1 x Speaker output - Frequency response 10 Hz - 250 Hz - Bass boost 0 - 12 dB / 30 - 80 Hz - Lowpass 50 Hz - 250 Hz adjustable - Bandpass 10 Hz - 250 Hz adjustable - Subsonic 10 Hz - 50 Hz adjustable - Phase 0 - 180° adjustable - Slope subsonic / lowpass 12 / 24 dB/Oct. - Signal-to-noise ratio analog input 95 dB (A-weighted) - Distortion (THD) 0.20 % - Damping factor 150 - Operating voltage 10.5 - 16 Volts (max. 5 sec. down to 6 Volts) - Idle current 800 mA - Fuse 3 x 40 A Maxi-fuse (APX) - Additional features: Active, adjustable crossover, bass boost, phase shift, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control - Dimensions (H x W x D) 50 x 320 x 154 mm.
