SounDigital 1600.1 BASSTRONIK - 2 Ohm

The Basstronik series is designed for more powerful and direct bass reproduction. This new series is designed for playing heavy subwoofers / mid-basses, which is why SounDigital has upgraded the power supply of the amplifiers to be the most biggest and most stable ever used in their amplifiers! The new series includes, among other things, a fixed adjustable low-pass and subsonic filter, which makes it significantly easier to control the crossover frequency for the bass range. With the switch-off button, the amplifier can still be used for large speaker systems in full-range operation. The SounDigital amplifiers benefit from high power in a compact space, are easy to install, simple to use, and fit anywhere. Thermal problems are unknown to these amplifiers the well-thought-out cooling principle and the extremely high efficiency prevent overheating during music operation. Power @ 4Ω: 1 X 1000 WRMS Power @ 2Ω: 1 X 1600 WRMS Frequency Response (-3dB): 5Hz ~ 20kHz Subsonic Filter: 5Hz ~ 40Hz Low Pass Filter (12dB/octave): 50Hz ~ 250Hz Bass Boost: 0dB ~ 10dB @ 35Hz Input Sensitivity (RCA): 0.2V ~ 2V Input Sensitivity (High Level input): 1.5V ~ 15V Operating Voltage: 10V ~ 16V Signal-Noise Ratio: 90.2dB Current Draw (Music): 82A Current Draw (Max): 164 Total Efficiency: 85% Damping Factor: 2000 Recommended Fuse (Music): 100A Recommended Battery: 120Ah Power cable size: 35mm² Speaker Cable size: 4.0mm² Remote Cable size: 1.5mm² Width: 136.2 / 5.4 in Length: 180.1mm / 7.1 in Height: 54.8 / 2.2 in
